KJELDAHL DIGESTION CUM DISTILLATION UNIT (MODEL NO. HVS-KDD-587)

KJELDAHL DIGESTION CUM DISTILLATION UNIT

(MODEL NO. HVS-KDD-587)

TECHNICAL SPECIFICATIONS: -

1. Kjeldahl Distillation Integrated micro controller based precile PID module with feather touch controls and 7" touch screen LCD display with PC connectivity for easy operation and data storage.

2. Automatic sequencing of all processes and Inbuilt titrator should be available

3. Process kill switch to halt the processing case of accidental door opening

4. Detachable bottom drip tray for extra protection against acid attack

5. Anytime alkali addition during the distillation cycle

6. Tube sensor that enables safe operating conditions in event of tube damage

7. Reagent refill levels sensor to avert regent dry out.

8. It should have Automatic steam addition, automatic alkali addition, and automatic boric acid addition.

9. Automatic energy efficient steam generator available either as stainless steel or borosilicate glass.

10. Automatic water level maintenance steam generator

11. Tube capacity: 250ml/400ml

12. It have steam power adjustment 10-100%

13. It have programmable distillation time from 1 to 99 minutes.

14. It have reagent level sensor, anytime alkali addition, tube error detection, door closer sensor, processor resume from stop, one point alkali and distilled water pump, two-point calibration for acid pump, real time monitoring of process parameters.

INTERNAL CODE: - KD.25613
