LAF (Laminar Air Flow) Horizontal (Model No: HV-1227)

LAF (Laminar Air Flow) Horizontal (Model No: HV-1227)


  • Rs. 153,120.00

LAF (Laminar Air Flow) Horizontal


Laminar Cabinets Inner Chamber & Outer Chamber made of stainless steel high efficiency particular air filters, to achieve the air purification upto 0.3 Microns in Working area. Working area 4 ft x 2 ft x 2 ft
Cleanliness Class 100, Velocity 90 FPM ±20%
Hepa Filter 99.999 % efficiency for particles >0.3 μm
Pre-Filter 85 %efficiency for particles >0.5 μm (Washable)
Cabinet Laminated High Quality Stainless Steel SS 304
Work Table 304 Stainless Steel
Airflow Speed Control Speed Controller (Three Step Speed Controller)
Blower High efficient centrifugal type with lifetime lubricated bearings
Light High intensity, low wattage >800 lux, Noise Level <55 dBA
Standard Accessories: Air/gas cock and mains power socket (16A), Power Supply 220-230V,50 Hz.

  • Microprocessor LCD Controller
  • Digital display for air flow rate
  • Transparent Front Door
  • Gauges Pressure (Statics Pressure Mano-Mater)
  • Magnahelic Gauge (for filter pressure)
  • U. V. Germicidal Tube in work area
  • Electronic Filter choke alarm
  • Spare HEPA Filters
  • Auto switch on/off for U.V. Germicidal tube & fluorescent light
  • Hour Meter for UV light

Product Internal Code: 8615
