Magnetic Induction V-Block Set (Model No. HVO-MB-6878-1)
HOVERLABS
Magnetic Induction V-Block Set
Specification:
- Range: 5-56mm
- Size (LxWxH): 49x58x46mm
- Pole Pitch: 2+2mm
- Parallelism of Four V grooves to top, bottom, left and right sides: 10µm
- Squareness of V grooves to back side: 10µm
Features
- Hold cylindrical workpieces for inspection and machining
- To be used on magnetic chucks
- Two V-blocks per set
- V groove on the top for large shafts
- V groove on the bottom for small shafts
- Hardness HRB70
- Copper magnetic strips
