Magnetic Stirrer With Hotplate (Model No. HV-MSH-24)

Magnetic Stirrer With Hotplate

Technical Specifications :

• Square/Disc optional Voltage[VAC] : 110/220
• Frequency[Hz] 50/60 : Power[W] : 500
• Max. stirring quantity（H2O) : [L] 2
• Stirring point position quantity[mm] : 80
• Motor type : brushless motor
• Speed range[rpm] : 200-1500
• Speed and temperature display : LCD
• Speed display accuracy[rpm] : 1Plate
• Material : Material Ceramic coating surface/Stainless steel
• Dimension of Plate[mm] : 135 or 155
• Heating Temperature Range[℃] : RT-380
• Temperature display accuracy[℃] : 0.1
• Temperature sensor of extra position : PT100(Optional)
• Dimension[mm] : 310×180×110
• Weight[kg] : 3.5
• Permissible ambient temperature[℃] : 5-40
• Permissible ambient humidity : 80%
