MICROPLATE ELISA READER (With Inbuilt Printer) (Model: HV-1260)

MICROPLATE ELISA READER (With Inbuilt Printer)

Model: HV-1261

Technical Specifications: -

Þ Light Source: - 6V, 1 OW tungsten halogen lamp, it can work over 5000 hours

Þ Wavelength Range Optical Filters: - 400 -750 nm 4 Standard filters: 405, 450, 492,630 nm, maximum 8 filters

Þ Measurement Methods: - Single wavelength, dual wavelength, two points method, dynamic assay, multiple wavelengths.

Þ Blank Ways: - Single well blank, multiple wells blank, rows and columns blank

Þ Calculation Method: - Absorbance, single point calibration, linear regression, quadratic curve, four parameters equation

Þ Measurement Speed: - Single wavelength < 3 seconds/96 wells, dual wavelength < 9 seconds/96 wells

Þ Measurement Range Resolution: - 0.0000-4.5000Abs 0.0001A

Þ Linearity: - ± 05% or < 0.025 A

Þ Repeatability Difference: - < 0.1% or± 0.0025A

Þ Rows and Columns Difference: - < 0.01 A

Þ Display: - Built-in XP system, 8" touch-screen, shows whole microplate results and calibration curve

Þ Save Information: - More than 300 test programs, results of 50 pieces of 96 well, 100000 test results

Þ Interface: - 4 USB two-way communication interface, 1 RS232, 1 VGA, 1 Keyboard connector, 1 mouse connector

Þ Environment: - Power supply 12V DC (1 OOV-240V wide input voltage range) temperature:5°-40°C

Þ External Dimension: - 52.5cm (20.7 in) x 42.0cm (16.5 in) x 26.0cm (10 20in)

Þ Net Weight: - 9 kg

Internal Code: - KD.8516.230808
