MICROPROCESSOR FLAME PHOTOMETERS (Model: HVL-96)

MICROPROCESSOR FLAME PHOTOMETERS

(Model: HVL-96)

Technical Specifications: -

Sensitivity-General Mode: Na: 0.5 ppm, K: 0.5 ppm, Li: 0.5 ppm, Ca:15 ppm Ba: 30ppm

Filters-Na & K Supplied (Ca, Li & Ba are optional at extra cost) optional filter are factory fitted only. 0.1 ppm/0.1 meq.

Resolution- 0.1ppm/0.1meq.

Reproducibility-<1% coefficient of variation for 20 consecutive samples using 10 ppm Na set as Maximum Standard up to 3% CV for 20 consecutive samples of Concentrations between 50 to 199 ppm for Barium.

Linearity-<2% error when 3 ppm Na/K and 5 ppm Li are set as Maximum Std.

Curve Fit Accuracy- ±2% of FS

Display- 128 x 64 Graphical LCD

Average Time-In-built in Software

Flame System -LPG & Dry Oil Free Air

Detector -Photodiode

Calibration-with up to 25 Standards of user choice with curve fitting software

(5 for each Element). Multiple Calibration Curves can be stored in the memory

Gas Control-Adjustable with knob

Flame Failure- Auto Detection

Gas Cutt off-Automatic

Ignition System- Auto Ignition

Automiser- Axial Flow Type

Dimensions-Instrument: 365 x 245 x 220 mm Approx. (LxBxH)

Printer-Provision for attachment of Dot-Matrix Printer with centronics parallel interface

PC Interface -USB

Power Supply -

Weight - Main Unit: 8 Kg. (Approx.)

Dimension-365x245x220mm (approx)

PRODUCT FEATURES

✓ Auto Gas Cutoff Facility

✓ Auto Flame Failure Detection Facility

✓ Facility Inbuilt Thermal Printer

✓ uP Based With Printer Interface

✓ Five Element Measurement In Single Aspiration of the Sample

✓ Curve Calibration Programmability using Maximum of 25 Standards

✓ Data Processing Through Curve Fitting Techniques-Least Squares, Quadratic

✓ Multiple Calibration Curves Saving Facility

✓ Samples Data Storage Facility

✓ Online Help Key

✓ Printer Attachment Facility

✓ Measurement in ppm & meq

✓ Setup Storage Facility up to 10 setups files

✓ Supplied with Compressor Unit

INTERNAL CODE: - KD. B-25729
