Main Features :
1. Double beam UV-VIS spectrophotometers adopt double beam optical system, and blazed holographic gratings. They have outstanding test precision and very competitive prices.
2. 8-inch color touch-screen, cutting-edge user interface, powerful functions, and easy operation.
3. With powerful functions, the equipment shows great performance in qualitative and quantitative testing, such as:
• Full-spectrum scanning • Linear regression
• Detailed spectrum scanning • Concentration direct reading
• Time-based kinetics determination • Peak/ Valley detecting
• GOTO A • Multi-wavelength measurement
4. The equipment is designed with sophisticated power protection system. With high capacity of internal memory, it can store testing results, scanned images, regression equations and correction data. Therefore, it follows a fast initialization when power on.
5. The instrument can be connected with dedicated printer, which can print testing results, or draw curve from spectral scanning, fixed wavelength time-based scanning, and linear regression.
6. With USB COM port the device can be connected to a PC, which can not only enhance theperformance in data testing and spectrum scanning, but also expand the memory to save more testing results.
Specifications :
- Focal Length : 160mm
- Grating : 1200 lines/mm
- Detector : Silicon Photocell
- Spstlrum Bandwidth : 1nm
- Wavelength Setling : 8-inch color touch-screen
- Wavelength Ranqe : 190-1100nm
- Wavelength Accuracy : ±0.5nm
- Wavelength Repeatability : ≤0.2nm
- Scanning Speed : Fast-Medium-Slow
- Stray Light : ≤0.03%T (at 220nm Nal. 360nm NaNo2 )
-
Photometric Range : 0.0-200.0%T ,-0.301 - 4.000A, 0.000-9999C"
- Photometric Accuracy : ±0.3%T,±0.002Abs (0-0.5A), ±0.004 Abs (0.5-1A)"
- Photometric Repeatability : ≤0.15%T ,0.001 Abs((0-0.5A), 0.002 Abs (0.5-1A)"
- Baseline : ≤±0.002A (200-1090nm)
- Noise : 100% (T) noisc≤0.15%(T), 0% (T) noise≤0.1%(T)
- Drifting : ≤0.0009 Abs/30min (250nm and 500nm after 2h warm up)
- Power : AC220V±22V 50Hz±1iHz, 200W
- Packaging Size : 740mm X 630mm X 450mm 0.21M', 35kg
Double beam optical system
- 8-inch color touch-screen
- Automatic zero and full scale adjustment
- Automatic wavelength settings
- Equipped with USB COM port
- UV WIN8 Spectrum Data Processing Software optional
- Thermal plotter optional
Standard Accessories :
- Operation manual: 1
- Quartz cuvette 1cm: 2pcs
- Power cable :1
- Fuse :2pes
Optional Accessories :
UV WINB spectrum aaia processing software Thermal plotter |
