MUFFLE FURNACE (MODEL NO. HV-138-MF)

MUFFLE FURNACE

(MODEL NO. HV-138-MF)

TECHNICAL SPECIFICATIONS: -

Overview: The Muffle Furnace is a high-performance heating device designed for laboratory and industrial applications that require precise temperature control. Constructed with a sturdy Mild Steel (M.S.) sheet, this furnace features a lightweight design, ensuring ease of handling and installation. It is efficiently insulated with ceramic wool to reduce heat loss and minimize weight, making it an ideal choice for environments where thermal efficiency and energy conservation are paramount.

Key Features: Sturdy M.S. Sheet Construction: The durable body is made from mild steel, ensuring long-lasting use in demanding conditions.

Lightweight Design: The compact structure makes the furnace easy to move and install while maintaining its strength and stability. Efficient Insulation: Ceramic wool insulation helps in reducing heat loss, enhancing energy efficiency and optimizing temperature control.

High Temperature Range: Capable of reaching a maximum temperature of 1000°C, with a continuous working temperature of up to 900°C.

Precise Temperature Control: Temperature is precisely regulated through an Energy Regulator or Digital Temperature Controller, providing accurate and consistent heating performance. The furnace is equipped with a thermocouple for reliable temperature measurement and a digital pyrometer display for clear, real-time monitoring.

Thermal Fuse Protection: For enhanced safety, the furnace can be fitted with an optional thermal fuse on specific requests to prevent overheating.

Power Supply: Operates efficiently on a 230 V AC supply.

Specifications: -

Internal Dimensions: 15 x 15 x 22 cm

Power Rating: 2.5 kW Maximum Temperature: 1000°C Working Temperature: 900°C Electrical Supply: 230V AC

Optional Accessories: -

•Thermal Fuse

•Solid State Fuse

INTERNAL CODE: - KD.25613
