Non-Contact Tachometer (Model No. HVO-9223-120)
Non-Contact Tachometer
Specification:
- Measuring Range: 2.5-99999RPM
- Resolution:
0.1 RPM (range 2.5-999.9RPM)
1RPM (range 1000-99999RPM
- Accuracy:
±(0.05%n+1d) RPM
n is rotary speed, d is resolution
- Laser power: Class 3R, 3mW~4mW
- Sampling Time: 0.6s (above 100 RPM)
- Measuring distance: 50~500mm
- Operation Temperature: 0~40°C
- Power Supply: 3xAA batteries
- Dimension: 180x71x28.9mm
- Weight: 145g
Features:
- Accurately measure the rotary speed without contact
- Automatically save the maximum value, minimum value and the last value, 500 data can be stored during continuous measurement
Standard Delivery:
- Main Unit: 1Pc
- Reflection Sticker: 3Pcs
- Battery (AA): 3Pcs
