Product details
Penta Head Teaching Microscope (Model: HVL-PH-01)
Technical Specification: -
Observation Heads
Trinocular observation head inclined at
30° rotatable at 360° (One set)
Binocular observation heads inclined at
30° fixed on adjustable stands. (Four Set)
Mechanical Body
Co-axial focusing control with large knob, Pre-Focusing Lever & Tension Adjustment Ring. Reverse angle sextuple nosepiece revolving on ball bearings. Mechanical stage size 185mmX142mm & having low positioned co-axial controls on ball bearing
guide ways.
Observation Heads
Trinocular observation head inclined at
30° rotatable at 360° (One set) Binocular observation heads inclined at 30° fixed on adjustable stands. (Four Set)
Eyepieces
Wide field Eyepiece 10X (paired) F.O.V. 20mm.
Objectives
CCIS Plan Achromatic 1.5X
CCIS Plan Achromatic 4X
CCIS Plan Achromatic 10X
CCIS Plan Achromatic 20X
CCIS Plan Achromatic 40X (S L)
CCIS Plan Achromatic 100X (S L) Oil
Mechanical Body
Co-axial focusing control with large knob, PRE
Focusing Lever & Tension Adjustment Ring.
Reverse angle sextuple nosepiece revolving on
ball bearings.
Mechanical stage size 185mmX142mm & having low positioned co-axial controls on ball bearing guide ways.
Illuminator
Koehler's illumination system with 24V-100W halogen lamp, adjustable brightness.
Sub Stage Condenser
Swing out top lens. Abbe condenser N.A 0.9/1.25 with swing out filter holder. Iris diaghragm, top lens.
Pointer
Dual color LED pointer, Brightness adjustable.
Standard Accessories
Blue & grey filters, LED bulb, halogen bulb 24V/100W, styrofoam boxes.
Internal Code: - KD.4089.260512
Warranty and support
Every HOVERLABS instrument carries a 1-year Ex-Works warranty against manufacturing defects. Units are stringently tested on numerous parameters, strictly adhering to tech. specs., before dispatch. Online installation, if required, is free (one time); physical installation is charged extra.
Shipping and payment
Free shipping across India with no packaging charges. Institutions can order via purchase order, NEFT/RTGS or UPI, and credit terms are available for eligible buyers. Add your GSTIN at cart for a GST tax invoice. Export enquiries: LC or wire transfer, all Incoterms.
Bulk, tender and GeM supply
We match BOQ specifications line by line and supply against purchase orders as well as GeM. Send your requirement list for a formal quotation, usually within one working day — Tenders & GeM.
