Polysomnography Machine, 16 Channel (Model No. HV-PSG-16)

Polysomnography Machine, 16 Channel (PSG Machine)

Salient Features:

• 16 Channel Raw data storage.
• Unlimited continuous recording.
• Event marking with comments.
• User definable montages.
• Ultra fast automatic paging facility for efficient analysis.
• Screen freeze facility to study event carefully.
• Make Autorun CD/DVD which can be played on any system with the software setup.

Auto Reporting

• Apneas & Hypopneas:


                 Obstructive
                 Mixed
                 Central

• Bifurcation of OSA, CSA, MSA, HYP in REM & NREM.
• Show Sleep Stages in Analysis.
• Automatic marking of K-Complexes, sleep spindles, REM.
• Spike & Seizure Detection.
• Detailed reporting of Oximeter, Heart rates, Snoring etc.
• Oximetry Histogram.
• Video Recording.
• Show CPAP Pressure Delivered to patient and during analysis.

Technical Specifications:

A/D Conversion : 16 bit ADC
Sampling Rate : 1024 Hz
Sensitivity : 1 to 1500 μV/mm & user definable.
Low pass filter : 0.1, 0.3, 0.5, 1, 3, 5, 7 Hz & user definable.
High pass filter : 0.1, 0.3, 0.5, 2, 10, 15, 35, 70, 99 Hz & user definable
Notch Filter : 50/60 Hz
Input lmpedence : > 10 M Ohms
CMRR : > 100 db
Noise level : < 0.3 μV RMS
