Portable Electric Autoclave Model: HV-PEA522

Portable Electric Autoclave

Brand: Hoverlabs

Model: HV-PEA522

Technical Specifications: -

Portable device top loading.

Electric generation of steam.

Also, gas and/or coal driven

Electrical requirements: power source 220V+/- 10%, 50/60 Hz, single phase, connection type F plug.

Maximum power required not greater than 1,5KW.

Sterilization chamber capacity of 15 liters ± 5 liters.

Working temperature minimum range from 115ºC to 121ºC.

Adjustable timer, approximate range 20 min to 30 min.

Sterilization max pressure not below 1.3 bars.

Integrated handles, heat resistant.

Internal steam electrical generator made of stainless steel.

Housing made of Stainless Steel AISI 304 or better steel.

Sterilization chamber made from stainless steel AISI 304, preferably AISI 316 or better steel.

Built-in colour code pressure gauge to show internal chamber pressure, at least one colour to indicate sterilization pressure and other as warning for overpressure. Alarms for at least: power failure, low water, door not closed, pressure and/or temperature out of limits, end of cycle.

Minimal maintenance required.

Built-in high-pressure faucet for water drainage.

Silicon seals.

Safety features:

- Locking system to avoid the lid to be opened during sterilization

- Over temperature protection;

- Dual overpressure protection: pressure release valve & pressure stopcock;

- Leakage protection;

- Water level gauge or other system that prevent the autoclave from running dry or with low water levels;

- Preferably with electronic temperature control using a PT100 sensor or equivalent.

Accessories included

Autoclave stand made of stainless steel.

At least 2 sterilizing stainless steel drums and 2 baskets.

Water deionizer or other water purifier that can produce the water quality and quantity to opportunely feed the autoclave.

Internal code: KD.9171.240729
