Portable Leeb Hardness Tester (Basic Type) (Model No. HVO-HDT-L411)

Portable Leeb Hardness Tester (Basic Type) (Model No. HVO-HDT-L411)

HOVERLABS

8
Free Shipping | No Packaging Charges | Click for Delivery Schedule | G.S.T@18% Extra

Portable Leeb Hardness Tester (Basic Type)

Specification:

  • Resolution: 1HLD, 1HV, 1HB, 0.1HRC, 0.1HRB, 0.1HRA, 0.1HS, 1SGM

  • Accuracy: ±6HLD (when HLD=800)
  • Output: USB
  • Measuring range: HL 100-960/HRC 1-74.7/HRB 1.2-140/HB 28-1027/HV 45-1230 HS 4-112/HRA7-88.5/SGM(rm) 118-3315N/mm2

  • Applicable Workpiece:

Minimum weight: 5kg (direct measurement), 2kg (on soil support), 0.05kg (coupled on plate)
Minimum thickness: 5mm
Minimum radius of curved surface: 30mm
Maximum roughness(Ra): 2μm

  • Power supply: 1xAAAbattery

  • Dimension: 148x45x21mm
  • Weight: 105g

          Standard Delivery:

          • Main Unit: 1Pc
          • Hardness Test Block D:1Pc
          • Cleaning brush: 1Pc
          • AAA Battery: 1Pc
          • Smart support ring: 1Pc
          • Software flash disk and USB cable: 1Pc

          Features:

          • Impact device D
          • Universal testing angle, no need to set impact direction
          • Dual-coil probe, high accuracy
          • Based on Leeb (HLD), converted to Vickers (HV), Brinell (HB), Rockwell (HRC, HRA and HRB), Shore (HS) and tensile strength (SGM)
          •  Dual value display, shows both Leeb and converted hardness
          • High contrast digital LCD display
          • Can choose large font display
          • Automatically calculate maximum, minimum, average value
          • Connected to PC via USB
          • Save 999 data
          • Operation temperature: -20°C-45°C
          • According to ASTM A956, DIN 50156, GB/T 17394
