RESEARCH MICROSCOPE WITH SEMI PLAN ACHROMAT OBJECTIVES

Technical Specifications:

• Optical System: Finite Optical System. All optics are be made of High quality glasses and Anti-Fungal coated.

• Stand: U Shaped stand with well-contoured modular base, Ergonomic easy-to-use Microscope have specifically been designed for laboratory and University  applications window in the arm section to observe the specimen with naked eye. Ergo-Nomic carrying grip enables easy transportation.
• Viewing head: Trinocular inclined tube, inclined at 45° rotatable through 360° with Ipd 50-75 mm and one side dioptric adjustment. Anti-Fungus treated

• Eyepieces: Wide Field Eyepiece Paired Wf 10x

• Nosepiece: Reverse Par Focal Quadruple Revolving Nosepiece (Ball Bearing Type).

• Objectives: Din Semi Plan Achromatic, Anti Fungus Treated Objectives 4x/ 0.10, 10x/ 0.25, 40x (Spring Loaded)/ 0.65, 100x (Spring Loaded, Oil)/ 1.25 all Objectives are par focal and precentered to minimize refocusing

• Stage: Double layer graduated mechanical rectangular stage size 132 X 142mm cross travel 75 (X) X 40 (Y) mm on ball Bear-Ing Co-Axial Controls, spring clip stage focus stop adjustable through focus locking screw.

• Focusing Module: Coaxial course & fine focusing mechanism, with tension

• Control Ring. Low positioned coaxial knobs for easy reach of the operator. thus eliminate operator for raising elbows while working.
• Condenser: Moveable abbe condenser, Na 1.25 with aspheric lens Iris diaphragm with swing our filter holder.

• Illumination: Built in bright white Led, with intensity control regulator

Internal Code: SA. 8653-240201
