Lab Centrifuge Digital, 5200 RPM (Model No. HV-8M)

Revolutionary General Purpose Lab, Centrifuge Digital, 5200 RPM

Technical Specifications:

• General Purpose Bench Top Laboratory Centrifuge Machine.
• Heavy duty C.R.C. construction finished with powder coating.
• Double walled ABS injection moulded lid which is light weight to avoid accident.
• Inter lid lock and metallic centrifuge bowl for safety.
• 2 lines of 16 character LCD display of r.p.m., R.c.f, set time and run time
• Microprocessor based programmable speed control from 500 to 5200 r.p.m depending upon the type of rotor and Digital timer (0-59 minutes)
• Last test parameter recall and display automatically on LCD.
• Low noise, smooth and soft start and stable Speed output.
• Wide variety of rotors and reduction adopters available on demand at extra cost.

Technical Parameter :

•   Max. Speed : 5250 r.p.m.
•   Max. RCF 'g'  : 3600
•   Max. capacity : 400 ml.
•   Motor : Universal Motor (fitted with carbon brushes)
•   Power :  AC 220V 50 Hz ±10%
•   Dimension of Machine : L = 415mm, W = 360mm, H = 305mm
•   Dimension of outer box : 510 x 510 x 390 mm
•   Nett Weight : 21kg. Approx. Gross Weight with box = 23.5Kg

Special Features :

• The lid is light in weight to avoid accident due to heavy weight metallic lids during operations
• Very stable and low noise
• No vibrations
• Motor fitted on anti vibration spring pads. supported with rubber covering from inside and out side.
