SCREW PUMP TEST RIG
(Model: HVL-06)
Technical Specifications: -
The setup is designed to study the performance of Screw pump.
Set up consists of a Screw pump having a pair of meshed Screws coupled with electrical motor, supply tank, measuring tank & pipe fittings for closed loop oil circulation. Pressure and Vacuum gauges are connected on delivery and suction side of pump for the purpose of measurement. The flow rate of water is measured using measuring tank and stop watch provided.
EXPERIMENTS
· To determine overall efficiency and pump efficiency of the Screw pump.
· To plot Head vs. Discharge, Pump efficiency vs. Discharge
FEATURES
· Closed loop circulation
· Compact & stand alone set up
· Stainless Steel tanks and wetted parts
· Superb Painted structure
· Simple to operate & maintain
UTILITIES REQUIRED
· Electric supply : 230+/- 10VAC,50Hz,1 ϕ
· Oil supply Oil @ 30 liters
· Floor Area with drain facility
|
Product & Code |
SCREW PUMP TEST RIG & HM 06 AC/DC |
|
Pump |
Screw pump with pair of meshed Screw sCapacity 1 HP, Speed 1500 RPM (max.), Head 5 kg/cm2 (max.) |
|
Drive |
HM 04 AC : AC motor with step cone pulley arrangement for 3prefixed speed |
|
Supply Tank |
Capacity 35 Ltrs. MOC SS |
|
Measuring Tank |
Capacity 20 Ltrs. MOC SS fitted with Piezometer Tube & scale |
|
Piping |
GI / PVC |
|
Stop Watch |
Electronic |
|
Pressure MeasuringInstruments |
Pressure Gauge: Bourdon type Vacuum Gauge: Bourdon type |
|
Control Panel |
With required electrical instrumentation RPM Indicator with Proximity Sensor Electronic Energy MeterOn /Off switch Main indicator etc. |
|
Overall Dimensions |
