Single Beam VIS Spectrophotometer Scanning Based (Model No. HV-41)
Specifications :
- Wavelength Range : 320 - 1100 nm
- Spectral Bandwidth : 2 nm
- Optical System : Single Beam, grating 1200 lines/mm
- Wavelength Accuracy : ± 0.5 nm
- Wavelength Repeatability : 0.3 nm
- Wavelength Resolution : 0.1 nm
- Photometric Accuracy : ± 0.3 %T or 0.003 A@1A
- Photometric Range : -0.3 to 3A,D-200% T,0-9999 cone.
- Photometric Repeatability : ±0.2%T
- Stray Light : <0.3%T
- Stability : ± 0.002A/h@50nm
- Display : 128 x 64 Dots Large Graphical LCD
- Photometric Mode : % Transmission, Absorbance and Concentration, Scanning etc.
- Keyboard : Soft Touch Membrane Keys
- Sample Compartment : Standard 4-Position 1 D mm pathlength cuvette holder. (Accommodates upto 1 DD mm path-length, cuvette with optional holder)
- Light Source : Tungsten Lamps
- Detector : Silicon Photodiode
- Output : USB for PC Connectivity and Parallel Port for Dot Matrex Printer
- PC Software : Basic PC Software provided for quantitative /kinetic analysis with Professional PC Software for additional wavelength scan and DNN Protein Test.
- Power : 230V±10% AC, 50 Hz
