Spray Extraction
Description
The setup is designed to demonstrate principles of spray extraction and mass transfer operation in a column.
The set up consists of a glass column, feed tanks, air regulator with pressure gauge, receiving trays and piping. Rota meter are provided for flow measurement.
Experiments
- Determination of overall height of a transfer unit and overall volumetric mass transfer coefficient
Features
- Stainless Steel tanks and wetted parts
- Special arrangement for changing height of interface zone
- Continuous operation
- Superb Painted structure
- Simple to operate & maintain
- Compact & stand alone set up
Utilities Required
- Electric supply: 230 +/- 10 VAC, 50 Hz, single phase
- Chemicals for trial as per your choice
- Compressed Air supply: Clean, oil and moisture free air, pressure 2 Bar.
Water Supply & Drain as required
Technical Specification
|
Extraction Column |
MOC Borosilicate Glass, Dia 45 mm, Height 500 mm (approx) with SS end cups & support plates |
|
Feed Tanks |
Material Stainless Steel (2 Nos.), Capacity 20 Ltrs. with level indicators, air release valves, charging funnel with valve, air pressure fittings, feed lines, drain valve etc. |
|
Flow Measurement |
Rotameter (One each for solvent & solute) |
|
Feed Circulation |
By Compressed Air, using PU pipe line & fittings Pressure Regulator Bourdon type (0-2 kg/cm2 ) Air compressor (Optional) |
|
Feed Piping |
Chemical Circulations By PVC/SS |
