Table Top Autoclave- Class B Fully Automatic (23-25ltr) (Model No.HVS-TA2-B)

Table Top Autoclave- Class B (20-25ltr)

Model No.: HVS-TA2-B

Type of Autoclave: B Class Steam Autoclave Table top, Front Loaded with a size of 25 Liters.
Chamber Size(mm): φ270*460
Sterilization Class: Class B
Sterilization Temperature: 121°C & 135°C adjustable
Max Working Temperature: 138.0 °C
Drying System: Vacuum drying system
Display: LCD display
Testing System: B&D Test, Vacuum Test, Helix Test
Test Pressure: 5.00 Bar
Control Precision: Temperature: 1℃, Pressure: 0.1bar
Sterilization Data: RS-232 / USB and printer (standard)
Safety System: Hand lock door, Pressure lock system, Relief valve in case of over pressure,
Pressure or temperature over load protection, Silicon Rubber Gasket is provided for Leak
Proofing, Alarm for system failure, finish reminding, water level warning and malfunction
indications.
Controller: Soft push buttons
Steam generator: External shall be present
Reservoir: Operating on Distilled Water, capacity 4-5 Liters
Air Removal Device: Vacuum Pump (Diaphragm Type)
Air Filter: Anti-Microbial air filter (Filtration efficiency >99 % for 0.3-micron particle)
Controls: Microprocessor
Dry Time: 4 – 30 minutes
Vacuum Pump: Max. vacuum – 82 Kpa; Flow rate 11L/min
Ambient Temp.: 5 ～ 40
Chamber: SUS304
Max working pressure: 2.3bar, Min working pressure: -0.9bar, Design temperature: 140℃
Water Supply System: Build-in water tank easy to clean
Water Tank Capacity: 3.5L
Water Consumption: 0.16L~0.18L in one cycle
Tray Holder: 3 pcs SS Wire Mesh Trays on SS shelf
Noise: <65dB
Consumption: 1950VA
Power Supply: Standard: 220V±10%,50Hz/60Hz; Optional: 110V±10%,50Hz/60Hz.
Wiring Method: Plug
External Size(W*D*H) mm: 540*600*440
Package Size(W*D*H) mm: 610*810*590
Gross Weight (kg): 50 kg (Apprx.)
Note: It is applicable to the altitude below 3000 meters, and the parts need to be changed when the altitude is over 2000 meters.

1. Chamber Construction
Corrosion-resistant, Surgical Grade Stainless steel 304
2. Build-in Open Type Water Tank
The sterilizer adopts easy clean open type water tank which can support repeated program running
if fully injected with water.
3. High-Efficiency Ultimate Vacuum
The sterilizer adopts high-efficiency low noise vacuum system which has excellent effects.
4. Large LCD Display
The LCD screen can display temperature in increments of 0.1°C, pressure, time, operating status,
failure warning and other information. It is convenient for users to observe the sterilizer running
status.
5. Door Lock
Double safety door lock with Pressure Lock System
6. Multiple Program Types
The system has various programs that include packed items, unpacked items, BD testing program,
vacuum testing program and drying function.
7. Standard USB Port
Users can store the sterilization data with RS-232 / USB.
8. Mini printer can be attached to record the process of sterilization.
