Total Organic Carbon Analyzer (Model No: HVO-TOC-6500)

Total Organic Carbon Analyzer (Model No: HVO-TOC-6500)


  • Rs. 1,268,025.00

Total Organic Carbon Analyzer


  • Equipped with conductivity detector to quantify TOC concentration.
  • Ideal choice to measure and monitor microelectronics water, purified water
  • Automatic sample introduction with one-button setting, no sample contamination, no harm on operator and environment.
  • UV oxidation by UV lamp, no need to add acid, gas or catalytic, greatly reduces the experiment and maintenance cost.
  • 7 inches touch screen with smart UI, easy to operate and read test data.
  • In compliance with FDA-21 CFR Part11 requirements and USP, EP.JP and ChP.
  • Auto sampler is optional according to different experiment requirements.
  • 8GB large storage capacity, no restriction of data and time.
  • Data can be retrieved and saved to USB directly.
  • Modular design for quick installation and easy maintenance.

Technical Specification:

  • Detection Range - 0.001-1.5mg/I
  • Detection Limit: 1ppb
  • Max Tolerance: ±5%
  • Analysis Time: 3 min
  • Response Time: Within 10 min
  • Sample Temperature: 1-95°C
  • Environment Temperature: 10-40°C with temperature change ±5 °C/d
  • Sample Flow Speed:  3m1/min
  • Relative Humidity: <85%
  • Repeatability Tolerance: <3%
  • Drifting: ±5%
  • Power Supply: AC 220V, 50/60Hz or AC 110V, 50/50Hz
  • Frequency: 50/60Hz
  • Rated Power: 100W
  • Dimension: 440*220*300mm
  • Equipped with Conductivity detector to quantify TOC Concentration.
  • 7-inch Touch Screen Display.
  • The system is password protected & in compliance with 21CFR Part 11 Requirements.
  • 8GB large storage memory.
  • Quick Test & Analysis in < 3 minutes.
