Product details
TRINOCULAR MICROSCOPE
MODEL: - HV-AJ-12TR
TECHNICAL SPECIFICATION: -
Observation Head: Trinocular Head
inclined rotatable through 360° interpupillary distance adjustment ring 54-74mm, diprotic adjustable Main Body: All part Pressure die cast to provide long life and good mechanical strength. Eyepieces: Wide field 10X or 15X Paired Objectives: 4X, 10X, 40/45x $. L. 100X Oil Immersion (S.L.) Nosepiece: Quadruple nosepiece revolves on ball bearing Mechanical Stage: Co-axial low positioned mechanical X-Y stage of size 120x125mm with fine vernier graduation. Condenser: Abbe Condenser N.A. 1.25 having aspherical lens, adjustable iris diaphragm Illumination: Built in base illumination system with 6V-20W halogen bulb and plano concave mirror attachment Suitable for 220V, 50Hz AC Supply or 3-watt LED Light Packing: Nicely packed in box
Observation Head: Trinocular Head.
inclined rotatable through 360° interpupillary distance adjustment ring 54-74mm, diprotic adjustable Main Body: All part Pressure die cast to provide long life and good mechanical strength.
Eyepieces: Wide field 10X or 15X Paired
Objectives: 4X, 10X, 40/45x $. L. 100X Oil Immersion (S.L.)
Nosepiece: Quadruple nosepiece revolves on ball bearing
Mechanical Stage: Co-axial low positioned mechanical X-Y stage of size 120x125mm with fine vernier graduation.
Condenser: Abbe Condenser N.A. 1.25 having aspherical lens, adjustable iris diaphragm
Illumination: Built in base illumination system with 6V-20W halogen bulb and plano concave mirror attachment
Suitable for 220V, 50Hz AC Supply or 3-watt LED Light
Packing: Nicely packed in box
INTERNAL CODE: - KD. 2323.25614
