XY-Axis Stage (Model No. HVO-X-6584-602)

XY-Axis Stage

Specification:

• Micrometer in the middle
• XY-Axis Displacement: ±6.5mm
• Parallelism of top to bottom surface: 0.06mm
• Micrometer Graduation: 0.01mm
• Micrometer Accuracy: 0.01mm
• Maximum Load: 49N (5kgf)
• Micrometer Location: Middle
• Stage Size: 60x60xmm
• Weight: 0.48kg

Features

• Cross roller guides, achieve high precision and smooth movement
• Stages made of aluminum alloy
